Hyte Y40 Black



  • Vertical Graphics Support
  • Included PCIE 4.0 Cable
  • 2 Pre-installed 120mm Fans
  • Side Mount Radiator Support Up to 280mm
  • Ceiling Mount – Radiator Support 360mm
  • Supports 4 slot GPU’s

Available on back-order

Category: Tags: ,


  • Package Type:Retail
  • Warranty:3 Years
  • Case Type:Mid Tower
  • Colour: Black
  • Material Chassis:
    • Tempered Glass
    • Steel
    • ABS
  • Side Panel:Tempered Glass
  • Front USB 3.0 Port(s):2
  • Front USB 3.2 Gen 2 Port(s) Type-C:1
  • Front Audio in/out Jack(s):1
  • Expansion Slots:4 + 6 half-height?
  • Motherboard Support:Mini ITX / Micro ATX / ATX
  • Drive Bay(s):1 x 3.5-inch HDD or 2 x 2.5-inch SSD
  • PSU Support:ATX
  • Pre-installed Fan(s) Rear:1 x 120mm
  • Pre-installed Fan(s) Bottom:1 x 120mm
  • Radiator Support:
    • Side: 120mm, 140mm, 240mm, 280mm up to 120mm thick
    • Top: 120mm, 240mm, 360mm
    • Rear: 120mm
  • Fan Support:
    • Side: 2 x 120mm/140mm
    • Top: 3x 120mm
    • Rear: 1 x 120mm
    • Bottom: 1x 120mm/140mm
  • Clearances:
    • Power Supply: ATX up to 224mm in length
    • Video Card Max Dimensions: 422mm length, 94mm height (80mm height or less recommended for best cooling)
  • Dust Filter(s):
    • Top
    • Side
    • 2 x Bottom
  • Product Width:240mm
  • Product Length:439mm
  • Product Height:472mm
  • Package Width:52cm
  • Package Length:53.5cm
  • Package Height:32.8cm
  • Gross Weight:9.37Kg
  • Special Features:
    • Multi-Dimensional Design: Details connect every part into a deeply harmonic design structure. Every edge is adorned in tightly controlled bevelling for s-tier aesthetics. 2-Piece Panoramic Glass set the stage for a completely unobstructed view of your system’s performance.
    • Ginormous Vertical Graphics Support: Y40 grows GPU support to 4 full slots with additional airflow space between the edge of the card and the glass. An intake fan below the power supply shroud provides fresh air upwards to the GPU to improve cooling further.
    • Included Luxury PCIE 4.0 Riser Cable: A protective riser cable canopy integrates beautifully into the case, allowing for half-height PCIE cards behind the throne of the vertical graphics card.
    • Cooling: Y40 comes with 2x 120mm fans pre-installed, one beneath the floor and one at the rear. The side mount can fit up to a 280mm radiator with a combined thickness of up to 120mm allowing for large 60mm+ radiators to be used for custom loop configurations, and the top mount can fit up to a 360mm radiator for dual radiator setups. Y40 also brings support for large air coolers over 180mm in height, allowing for almost every CPU cooler on the market.
  • Package Contents:
    • Y40 ATX Case
    • Instructions
    • PC Headset Adapter
    • PCI Express Riser Cable 4.0 x16
    • Accessory Box
    • Zip Ties
