Description
Product Description
Asrock B560M-HDV, Intel B560, 1200, Micro ATX, 2 DDR4, VGA, DVI, HDMI, 2x M.2
Motherboard Type
Desktop
Form Factor
Micro ATX
Socket
Intel 1200 – Rocket Lake
Chipset
Intel B560
CPU Support
Click here for CPU support
RAM Technology
DDR4 (Dual Channel)
RAM Slots
2 x DIMM
RAM Speeds
Up to 5000+(OC)
Maximum Memory
64GB
Graphics
Integrated Graphics*
*Graphics specifications may vary between CPU types
Graphics Ports
1 x VGA
1 x DVI-D
1 x HDMI
1 x DVI-D
1 x HDMI
Multi-GPU Support
–
PCI/PCI Express
1 x PCIe 4.0 x16
2 x PCIe 3.0 x1
2 x PCIe 3.0 x1
Storage
4 x SATA III
1 x M.2 (2260/2280) – PCIe
1 x M.2 (2260/2280) – SATA & PCIe
1 x M.2 (2260/2280) – PCIe
1 x M.2 (2260/2280) – SATA & PCIe
RAID
–
Wireless
–
LAN
GB LAN
Audio
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
USB Ports Supported
6 x USB 3.2 Gen1 (4 at back, 2 at mid-board)
6 x USB 2.0 (2 at back, 4 at mid-board)
6 x USB 2.0 (2 at back, 4 at mid-board)
Back Panel I/O Ports
1 x PS/2 Mouse/Keyboard
1 x D-Sub
1 x DVI-D
1 x HDMI
2 x USB 2.0
4 x USB 3.2 Gen1
1 x RJ-45 LAN
HD Audio Jacks
1 x D-Sub
1 x DVI-D
1 x HDMI
2 x USB 2.0
4 x USB 3.2 Gen1
1 x RJ-45 LAN
HD Audio Jacks
Internal I/O Connectors
1 x COM Port
1 x SPI TPM
1 x Chassis Intrusion and Speaker
1 x CPU Fan
1 x CPU/Water Pump Fan
2 x Chassis/Water Pump Fan
1 x 24 pin ATX
1 x 8 pin 12V
1 x Front Audio
2 x USB 2.0
1 x USB 3.2 Gen1
1 x SPI TPM
1 x Chassis Intrusion and Speaker
1 x CPU Fan
1 x CPU/Water Pump Fan
2 x Chassis/Water Pump Fan
1 x 24 pin ATX
1 x 8 pin 12V
1 x Front Audio
2 x USB 2.0
1 x USB 3.2 Gen1
Accessories
2 x SATA Data Cables
2 x Screws for M.2 Sockets
2 x Screws for M.2 Sockets
Additional Features
See Overview
Package Type
Retail
Package Weight
0.8600 kg
Manufacturer Warranty
2 Year Replacement Manufacturer Warranty
