Description
Product Description
Arctic Liquid Freezer II 240 ARGB 240mm Liquid CPU Cooler, PWM Fans & PWM Controlled Pump
Type
Liquid CPU Cooler
AMD/Intel
Combo
Compatibility
Intel: 1200, 115x, 2011-3, 2066
AMD: AM4
Fan Connector(s)
4-pin
Installation
Cooler: 4 pin PWM Connector
LEDs: 4-pin 12V-G-R-B Connector with Y-Splitter
LEDs: 4-pin 12V-G-R-B Connector with Y-Splitter
Colour
Black
LED Lighting
12 A-RGB LEDs per Fan
Connector: 3 pin 5 V-DI-Gnd
Connector: 3 pin 5 V-DI-Gnd
Material
Cold Plate: Copper, Micro-Skived-Fins
Weight
1213 g (2 Fans, Radiator, Pump, Tubes)
Fan Dimensions
2 x 120mm Arctic P12 PWM A-RGB fans
Dimensions
Radiator: 277 x 120 x 38 mm
Pump (w/o tubes): 98 mm x 78 mm x 53 mm
Tube Diameter: Outer: 12,4 mm // Inner: 6,0 mm
Tube Length: 450 mm
Pump (w/o tubes): 98 mm x 78 mm x 53 mm
Tube Diameter: Outer: 12,4 mm // Inner: 6,0 mm
Tube Length: 450 mm
Fan Controller
PWM
Rotation Speed
VRM Fan: 1000 – 3000 RPM (PWM controlled)
Pump: 800 – 2000 RPM (PWM controlled)
Fan Speed: 200 – 1800 RPM
Pump: 800 – 2000 RPM (PWM controlled)
Fan Speed: 200 – 1800 RPM
Fan Bearing
Fluid dynamic bearing
Air Flow
48.8 CFM
Noise level
0.3 Sone
Power
Pump/Cold Plate Consumption: 0.5 W – 2.7 W (Pump + VRM Fan)
Fan Voltage / Current: 0.08 A / 12 V DC
RGB Current/Voltage: 0.4 A/ 5 V
Fan Voltage / Current: 0.08 A / 12 V DC
RGB Current/Voltage: 0.4 A/ 5 V
Additional Features
See Overview
Package Type
Retail
Package Weight
1.8050 kg
Manufacturer Warranty
6 Years
